Application
Use in instrumentation and control engineering where low current consumptions are required and transmission of the data must be continuous. These cables are ideal for voice communication in telecommunications system, for pulse, signal, data transmission application, in public address, two way intercom system and for all applications where high frequency interference can occur.
Cores Colour
| JZ | : Black cores with white numbering +yellow - green |
| OZ | : Black cores with white numbering |
| JB | : Coloured cores according to VDE 0293 + yellow - green |
| OB | : Coloured cores according to VDE 0293 |
Construction
Stranded bare copper conductor, fine wire strand structure as per IEC 60228, class 5
PVC insulated cores
Core twisted in layers
Film wrapping Tinned copper wire braided screening,approx.85 % coverage PVC outer sheath Sheath colour : grey, RAL7001 Electrical & Technical Data
| Working voltage Uo/U | : 300/500 V |
| Test Voltage | : 1000 VAC/1 min |
| Insulation Resistance | : ≥ 20 MΩ x km |
| Min. Bending Radius | : approx. 15 x cable diameter |
| Temperature range | : -50C to 700C (moved) |
| -300C to + 700C (Unmoved) | |
| Flame retardancy | : IEC 60332-1 |
Brand : Delta / IMC
Category : Control & Instrument Cable
Type : LIYCY
Price : Chat/Call
